Demonstration of XFdtd's Electrostatic Discharge (ESD) Testing Features

Learn how to use XF's features for ESD testing as we walk through the process of analyzing a multi-layer PCB and identifying potential locations of dielectric breakdown.

Using a simplified ESD probe to excite the PCB with ESD waveforms, we demonstrate the following features:

User-defined ESD waveforms
Dielectric strength material property
Dielectric breakdown near field sensor
Max Component Voltages and Currents dialog
Dielectric breakdown ratio
